Machine Specifications
• Working area 59.1in x 118.1in
• Laser power up to 3.5kw
• Transmission System Sync-dual Servo rack and pinion system
• Positioning speed(MAX) 2345 in/min
• Positioning accuracy ±0.001in/39.4in
•Repositioning accuracy of clamp ±0.0008in/39.4in
• Format DXF and NC
• Equipment power 12KW (laser and chiller not included)
• Power supply Three phase 480V
• Total weight 15432lb
• Overall size 343in×113in×89in
Core Part Structure
• Highly rigidity enhanced aviation aluminum gantry
• Gantry double rack & pinion, double servo motor transmission structure, high inertia and large torque output
• Integrated structure design, reasonable overall layout
• Gantry double rack & pinion, double servo motor transmission structure, high inertia and large torque output
• Integrated structure design, reasonable overall layout
 |
 |
