Specifications
| Cycle Speed | 4 seconds / 90 no load / 3.5 rpm |
| Max. Bend Angle | 180 degrees + spring back |
| Speed Reduction | Oil Bath with solid stock gears |
| Motor Power | 2.75 HP. Self Braking TEFC 3 Phase 220V* |
| Weight | 418 pounds without tooling |
*Machine requires 220V Three Phase Power – To run on single phase requires an ample sized Rotary Phase Converter at least with 10HP Rating Hard Starting load.
Maximum Bending Capacity
| Pipe | 1-1/2″ Sch. 40 Pipe |
| Tube | 2.25″ x 0.135″ |
| Round Bar | 1.25″ |
| Square Tube | 1.25″ |
Extraordinary Features
| All Steel Construction: Heavier than other makes of tube benders for maximum versatility and safety. NO Cast frame components! | Manual – Automatic: Auto function allows automatic bend & return with one command, programmable dwell time after bend/before return to allow part extraction. | |
| Adjustable Bend Angle Present: By means of PLC push button control with memory | Bends up to 180 degrees in one Step Quick Change Tooling Wide Range of Bending Radii: From 2″ to 10″ as tooling types permit. |
 |
 |
