Specifications
| Cycle Speed | 3.5 seconds / 90 no load |
| Max. Bend Angle | 180 degrees + spring back |
| Speed Reduction | Oil Bath with solid stock gears |
| Motor Power | 4.5 HP Self Braking TEFC 3 Phase 220V* |
| Weight | 1,200 pounds without tooling |
*Machine requires 220V Three Phase Power – To run on single phase requires an ample sized Rotary Phase Converter at least with 10HP Rating Hard Starting load.
Maximum Bending Capacity
| Pipe | 3″ Sch. 40 or up to 2-1/2″ Sch. 80 Pipe |
| Tube | 3.5″ x 0.216″ |
| Round Bar | 2″ |
| Square Tube | 2-1/2″ x 2-1/2″ |
Extraordinary Features
| All Steel Construction: Heavier than other makes of tube benders for maximum versatility and safety. NO Cast frame components! | Adjustable Bend Angle Present: By means of PLC push button control with memory | |
| Manual – Automatic: Auto function allows automatic bend & return with one command, programmable dwell time after bend/before return to allow part extraction. | Bends up to 180 degrees in one Step Quick Change Tooling Wide Range of Bending Radii: From 2″ to 19″ as tooling types permit. |
 |
 |
